SN65LVDT390D Texas Instruments

Please contact us for more photos of SN65LVDT390D

Part Number	SN65LVDT390D
Manufacturer	Texas Instruments
Quantity in stock	468210 Pieces
Market Price	-
Our Better Price	Send by email: [email protected]
Delivery Time	1 day (can ship today)
Description	LVDS Receiver 16-Pin SOIC Tube
Category	Interface IC
Family	LVDS
ROHS Compliant	Yes
MSL Level	SN65LVDT390D
Datasheet download	SN65LVDT390D.pdf

Request Quotation for SN65LVDT390D

SN65LVDT390D Specifications

Part Number	SN65LVDT390D
Differential Input High Threshold Voltage	0.1 V
Number of Drivers	4
Input Type	LVDS
Maximum Power Dissipation	950 mW
Product Dimensions	10 x 4 x 1.5 mm
Lead Finish	Gold
Typical Operating Supply Voltage	3.3 V
Number of Elements per Chip	4
Max Processing Temp	260
Rad Hard	No
Operating Temperature	-40 to 85 °C
Pin Count	16
Transmission Data Rate	630 Mbps
Differential Input Low Threshold Voltage	-0.1 V
Number of Receivers	4
Minimum Operating Supply Voltage	3 V
Maximum Operating Supply Voltage	3.6 V
Mounting	Surface Mount
Supplier Package	SOIC
Maximum Propagation Delay Time	4 ns
Maximum Input Current	40 uA
MSL Level	1
Output Type	Receiver
Package	16SOIC
Replacement Part Number	PART-SN65LVDT390D
Weight	Contact us
Country of Origin	-
