Please contact us for more photos of TM4C123BH6PZI
| Part Number | TM4C123BH6PZI |
|---|---|
| Manufacturer | Texas Instruments |
| Quantity in stock | 484510 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | MCU 32-Bit Tiva C ARM Cortex M4F RISC 256KB Flash 1.2V 3.3V 100-Pin LQFP Tray Tube |
| Category | Microcontrollers MCU IC |
| Family | ARM Based Microcontrollers MCU |
| ROHS Compliant | Yes |
| MSL Level | TM4C123BH6PZI |
| Datasheet download |  TM4C123BH6PZI.pdf |
| Part Number | TM4C123BH6PZI |
|---|---|
| Program Memory Size | 256 KB |
| Data Memory Size | 2 KB |
| RAM Size | 32 KB |
| Rad Hard | No |
| Pin Count | 100 |
| Operating Temperature | -40 to 85 °C |
| Maximum Speed | 80 MHz |
| Watchdog | 2 |
| Operating Supply Voltage | 1.2|3.3 V |
| MSL Level | 3 |
| Max Processing Temp | 260 |
| Mounting | Surface Mount |
| On-Chip ADC | 2(22-chx12-bit) |
| Minimum Operating Supply Voltage | 1.08|2.97|3.15 V |
| Data Bus Width | 32 Bit |
| Special Features | CAN Controller |
| Program Memory Type | Flash |
| Supplier Package | LQFP |
| Maximum Operating Supply Voltage | 1.32|3.63 V |
| Product Dimensions | 14.2(Max) x 14.2(Max) x 1.45(Max) |
| Instruction Set Architecture | RISC |
| Device Core | ARM Cortex M4F |
| Analog Comparators | 3 |
| Screening Level | Industrial |
| Lead Finish | Gold Over Nickel Palladium |
| Interface Type | CAN/I2C/SPI/SSI/UART/USB |
| Number of Timers | 12 |
| Number of Programmable I/Os | 69 |
| Package | 100LQFP |
| Replacement Part Number | PART-TM4C123BH6PZI |
| Weight | Contact us |
| Country of Origin | - |
