Please contact us for more photos of TPA3131D2RHBR
| Part Number | TPA3131D2RHBR |
|---|---|
| Manufacturer | Texas Instruments |
| Quantity in stock | 864210 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Audio Amp Speaker 2-CH Stereo Class-D 32-Pin VQFN T R |
| Category | Amplifiers IC |
| Family | Audio Amplifier |
| ROHS Compliant | Yes |
| MSL Level | TPA3131D2RHBR |
| Datasheet download |  TPA3131D2RHBR.pdf |
| Part Number | TPA3131D2RHBR |
|---|---|
| Amplifier Type | Class-D |
| Rad Hard | No |
| Maximum Load Resistance | 8 Ohm |
| Pin Count | 32 |
| Operating Temperature | -40 to 85 °C |
| Supplier Package | VQFN |
| MSL Level | 3 |
| Typical Supply Current | [email protected] mA |
| Typical Voltage Gain | 36 dB |
| Minimum Dual Supply Voltage | 4.5 V |
| Mounting | Surface Mount |
| Max Processing Temp | 260 |
| Output Signal Type | Differential |
| Typical Dual Supply Voltage | 5|9|12|15|18|24 V |
| Product Dimensions | 5.15(Max) x 5.15(Max) x 0.95(Max) |
| Maximum Dual Supply Voltage | 26 V |
| Screening Level | Industrial |
| Function | Speaker |
| Input Signal Type | Differential |
| Output Type | 2-Channel Stereo |
| Typical Output Power x Channels @ Load | 7.3x2@4Ohm W |
| Total Harmonic Distortion Noise | 0.1@[email protected] % |
| Rail to Rail | No |
| Lead Finish | Gold Over Nickel Palladium |
| Power Supply Type | Dual |
| Package | 32VQFN |
| Replacement Part Number | PART-TPA3131D2RHBR |
| Weight | Contact us |
| Country of Origin | - |
