TPS22920YZPR Texas Instruments

TPS22920YZPR Images

Please contact us for more photos of TPS22920YZPR

Part Number	TPS22920YZPR
Manufacturer	Texas Instruments
Quantity in stock	696310 Pieces
Market Price	-
Our Better Price	Send by email: [email protected]
Delivery Time	1 day (can ship today)
Description	Power Switch 4A 8-Pin DSBGA T R
Category	Power Management IC
Family	Power Switch
ROHS Compliant	Yes
MSL Level	TPS22920YZPR
Datasheet download	TPS22920YZPR.pdf

Request Quotation for TPS22920YZPR

TPS22920YZPR Specifications

Part Number	TPS22920YZPR
Product Dimensions	1.9 x 0.9 x 0.3 mm
Minimum Output Current	4 A
Switch On Resistance	0.0073 Ohm
Number of Outputs	1
Lead Finish	Tin/Silver/Copper
Input Voltage	0.75 to 3.6 V
Operating Temperature	-40 to 85 °C
Supplier Package	DSBGA
Max Processing Temp	260
MSL Level	1
Mounting	Surface Mount
Pin Count	8
Rad Hard	No
Package	8DSBGA
Replacement Part Number	PART-TPS22920YZPR
Weight	Contact us
Country of Origin	-
