Please contact us for more photos of TPS54202DDCR
| Part Number | TPS54202DDCR |
|---|---|
| Manufacturer | Texas Instruments |
| Quantity in stock | 899900 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conv DC-DC Single Step Down 4.5V 28V 6-Pin TSOT-23 T R |
| Category | Power Management IC |
| Family | DC to DC Converter |
| ROHS Compliant | Yes |
| MSL Level | TPS54202DDCR |
| Datasheet download |  TPS54202DDCR.pdf |
| Part Number | TPS54202DDCR |
|---|---|
| Type | Step Down |
| Maximum Output Current | 2 A |
| Operating Supply Voltage | 4.5 to 28 V |
| Number of Outputs | 1 |
| Switching Regulator | Yes |
| Minimum Input Voltage | 4.5 V |
| Output Type | Adjustable |
| Switching Frequency | 390 to 590 kHz |
| Package Dimensions | 2.9 x 1.6 x 1 mm |
| Supplier Package | TSOT-23 |
| Mounting | Surface Mount |
| Rad Hard | No |
| Lead Finish | Copper|Tin |
| Maximum Input Voltage | 28 V |
| Screening Level | Extended Industrial |
| Operating Temperature | -40 to 125 °C |
| Pin Count | 6 |
| Maximum Processing Temperature | 260 °C |
| Moisture Sensitivity Level | 1 |
| Output Voltage | 0.6 to 26 V |
| Package | 6TSOT-23 |
| Replacement Part Number | PART-TPS54202DDCR |
| Weight | Contact us |
| Country of Origin | - |
