Please contact us for more photos of TPS62205DBVR
| Part Number | TPS62205DBVR |
|---|---|
| Manufacturer | Texas Instruments |
| Quantity in stock | 329350 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conv DC-DC Single Step Down 2.5V to 6V 5-Pin SOT-23 T R |
| Category | Power Management IC |
| Family | DC to DC Converter |
| ROHS Compliant | Yes |
| MSL Level | TPS62205DBVR |
| Datasheet download |  TPS62205DBVR.pdf |
| Part Number | TPS62205DBVR |
|---|---|
| Supplier Package | SOT-23 |
| Product Dimensions | 2.9 x 1.6 x 1.15 mm |
| Operating Supply Voltage | 2.5 to 6 V |
| Efficiency | 95 % |
| Output Type | Fixed |
| Lead Finish | Gold |
| Switching Frequency | 1000 kHz |
| Output Voltage | 2.5 V |
| Minimum Input Voltage | 2.5 V |
| MSL Level | 1 |
| Type | Step Down |
| Rad Hard | No |
| Operating Temperature | -40 to 85 °C |
| Line Regulation | 0.26 %/V |
| Switching Regulator | Yes |
| Number of Outputs | 1 |
| Maximum Output Current | 0.3 A |
| Maximum Input Voltage | 6 V |
| Mounting | Surface Mount |
| Max Processing Temp | 260 |
| Load Regulation | 0.0014 %/mA |
| Pin Count | 5 |
| Package | 5SOT-23 |
| Replacement Part Number | PART-TPS62205DBVR |
| Weight | Contact us |
| Country of Origin | - |
