Please contact us for more photos of D55342E07B10B0RWS
| Part Number | D55342E07B10B0RWS |
|---|---|
| Manufacturer | Vishay |
| Quantity in stock | 793010 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Res Thin Film 1206 10K Ohm 0.1% 1 4W \u00b125ppm \u00b0C 0.01% Molded SMD SMD Waffle Pack |
| Category | Resistor |
| Family | Resistor Fixed Single-Surface Mount |
| ROHS Compliant | Yes |
| MSL Level | D55342E07B10B0RWS |
| Datasheet download |  D55342E07B10B0RWS.pdf |
| Part Number | D55342E07B10B0RWS |
|---|---|
| Resistance Value | 10 kOhm |
| Tolerance | 0.1 % |
| Temperature Coefficient | ±25 ppm/°C |
| Product Dimensions | 3.2 x 1.6 x 0.84 mm |
| Max Processing Temp | 260 |
| Case Style | Molded |
| Rad Hard | No |
| Case Size | 1206 |
| Mounting | Surface Mount |
| Power Rating | 0.25 W |
| Lead Finish | Tin/Lead |
| Operating Temperature | -55 to 125 °C |
| Product Depth | 1.6 mm |
| Product Height | 0.84 mm |
| Product Length | 3.2 mm |
| Replacement Part Number | PART-D55342E07B10B0RWS |
| Weight | Contact us |
| Country of Origin | - |
