Please contact us for more photos of D55342E07B180ERWI
| Part Number | D55342E07B180ERWI |
|---|---|
| Manufacturer | Vishay |
| Quantity in stock | 573420 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Res Thin Film 1206 180KOhm 1% 1 4W \u00b125ppm \u00b0C Molded SMD Waffle |
| Category | Resistor |
| Family | Resistor Fixed Single-Surface Mount |
| ROHS Compliant | Yes |
| MSL Level | D55342E07B180ERWI |
| Datasheet download |  D55342E07B180ERWI.pdf |
| Part Number | D55342E07B180ERWI |
|---|---|
| Rad Hard | No |
| Failure Rate | R |
| Military Standard | MIL-PRF-55342 |
| Mounting | Surface Mount |
| Temperature Coefficient | ±25 ppm/°C |
| Maximum Processing Temperature | 260 °C |
| Supplier Package | 1206 |
| Type | Thin Film |
| Pin Count | 2 |
| Lead Finish | Tin|Lead Over Nickel |
| Case Style | Molded |
| Operating Temperature | -55 to 150 °C |
| Case Size | 1206 |
| Resistance Value | 180 kOhm |
| Tolerance | 1 % |
| Package Dimensions | 3.2 x 1.6 x 0.84 mm |
| Termination Style | Wraparound |
| Power Rating | 1/4 W |
| Product Depth | 1.6 mm |
| Product Height | 0.84 mm |
| Product Length | 3.2 mm |
| Replacement Part Number | PART-D55342E07B180ERWI |
| Weight | Contact us |
| Country of Origin | - |
