Please contact us for more photos of IHLP1616ABER1R0M01
| Part Number | IHLP1616ABER1R0M01 |
|---|---|
| Manufacturer | Vishay |
| Quantity in stock | 481790 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Ind High Current Shielded Wirewound 1uH 20% 100KHz 4A 1616 T R |
| Category | Inductor |
| Family | Inductor Surface Mount |
| ROHS Compliant | Yes |
| MSL Level | IHLP1616ABER1R0M01 |
| Datasheet download |  IHLP1616ABER1R0M01.pdf |
| Part Number | IHLP1616ABER1R0M01 |
|---|---|
| Protection Style | Shielded |
| Operating Temperature | -55 to 125 °C |
| Lead Finish | Tin |
| MSL Level | 1 |
| Package/Case | 1616 |
| Technology | Wirewound |
| Product Dimensions | 4.7 x 4.31 x 1.2 mm |
| Rad Hard | No |
| Tolerance | 20 % |
| Max Processing Temp | 260 |
| Type | High Current |
| Test Frequency | 100 kHz |
| Product Depth | 4.31 mm |
| Product Height | 1.2 mm |
| Product Length | 4.7 mm |
| Replacement Part Number | PART-IHLP1616ABER1R0M01 |
| Weight | Contact us |
| Country of Origin | - |
