Please contact us for more photos of K473K15X7RF5TH5
| Part Number | K473K15X7RF5TH5 |
|---|---|
| Manufacturer | Vishay |
| Quantity in stock | 190880 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Cap Ceramic 0.047uF 50V X7R 10% Radial 5mm 125\u00b0C T R |
| Category | Capacitors |
| Family | Capacitor Ceramic Multilayer |
| ROHS Compliant | Yes |
| MSL Level | K473K15X7RF5TH5 |
| Datasheet download |  K473K15X7RF5TH5.pdf |
| Part Number | K473K15X7RF5TH5 |
|---|---|
| Product Dimensions | 4 x 2.5 x 4 mm |
| Package/Case | 4(Max) X 2.5(Max) X 4(Max) |
| Voltage(DC) | 50 V |
| Capacitance Value | 0.047 uF |
| Lead Diameter | 0.5 mm |
| Mounting | Through Hole |
| Termination Style | Radial |
| Lead Pitch For Radial | 5 mm |
| Case Style | Dipped |
| Rad Hard | No |
| Tolerance | 10 % |
| Wire Form | Outside Bend |
| Operating Temperature | -55 to 125 °C |
| Dielectric | C0G |
| Seated Plane Height | 6.54 mm |
| Max Processing Temp | 260 |
| Lead Finish | Tin |
| Product Depth | 2.5(Max) mm |
| Product Height | 4(Max) mm |
| Product Length | 4(Max) mm |
| Product Weight | 0.15 gram |
| Replacement Part Number | PART-K473K15X7RF5TH5 |
| Weight | Contact us |
| Country of Origin | - |
