Please contact us for more photos of M55342E12B3B48RT1
| Part Number | M55342E12B3B48RT1 |
|---|---|
| Manufacturer | Vishay |
| Quantity in stock | 485430 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Res Thin Film 0603 3.48K Ohm 0.1% 1 10W \u00b125ppm \u00b0C Molded SMD T R |
| Category | Resistor |
| Family | Resistor Fixed Single-Surface Mount |
| ROHS Compliant | Yes |
| MSL Level | M55342E12B3B48RT1 |
| Datasheet download |  M55342E12B3B48RT1.pdf |
| Part Number | M55342E12B3B48RT1 |
|---|---|
| Lead Finish | Tin|Lead Over Nickel |
| Mounting | Surface Mount |
| Package Dimensions | 1.62 x 0.81 x 0.84 mm |
| Case Size | 0603 |
| Maximum Processing Temperature | 260 °C |
| Type | Thin Film |
| Failure Rate | R |
| Package Type | |
| Temperature Coefficient | 25 ppm/°C |
| Power Rating | 1|10 W |
| Supplier Package | 0603 |
| Rad Hard | No |
| Tolerance | 0.1 % |
| Pin Count | 2 |
| Military Standard | MIL-PRF-55342 |
| Operating Temperature | -55 to 150 °C |
| Case Style | Molded |
| Termination Style | Wraparound |
| Resistance Value | 3.48 kOhm |
| Product Depth | 0.81 mm |
| Product Height | 0.84 mm |
| Product Length | 1.62 mm |
| Replacement Part Number | PART-M55342E12B3B48RT1 |
| Weight | Contact us |
| Country of Origin | - |
