Please contact us for more photos of M55342H12B470DRWS
| Part Number | M55342H12B470DRWS |
|---|---|
| Manufacturer | Vishay |
| Quantity in stock | 156520 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Res Thin Film 0603 470 Ohm 1% 1 10W \u00b150ppm \u00b0C Molded SMD Waffle Pack |
| Category | Resistor |
| Family | Resistor Fixed Single-Surface Mount |
| ROHS Compliant | Yes |
| MSL Level | M55342H12B470DRWS |
| Datasheet download |  M55342H12B470DRWS.pdf |
| Part Number | M55342H12B470DRWS |
|---|---|
| Pin Count | 2 |
| Temperature Coefficient | ±50 ppm/°C |
| Product Dimensions | 1.62 x 0.81 x 0.84(Max) |
| Max Processing Temp | 260 |
| Case Size | 0603 |
| Rad Hard | No |
| Case Style | Molded |
| Power Rating | 0.1 W |
| Mounting | Surface Mount |
| Tolerance | 1 % |
| Lead Finish | Tin|Lead Over Nickel |
| Resistance Value | 470 Ohm |
| Supplier Package | 0603 |
| Operating Temperature | -55 to 150 °C |
| Termination Style | Wraparound |
| Product Depth | 0.81 mm |
| Product Height | 0.84(Max) mm |
| Product Length | 1.62 mm |
| Replacement Part Number | PART-M55342H12B470DRWS |
| Weight | Contact us |
| Country of Origin | - |
