Please contact us for more photos of PLT0805Z6642BSTS
| Part Number | PLT0805Z6642BSTS |
|---|---|
| Manufacturer | Vishay |
| Quantity in stock | 680690 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Res Thin Film 0805 66.4K Ohm 0.1% 1 4W \u00b15ppm \u00b0C Molded SMD T R |
| Category | Resistor |
| Family | Resistor Fixed Single-Surface Mount |
| ROHS Compliant | Yes |
| MSL Level | PLT0805Z6642BSTS |
| Datasheet download |  PLT0805Z6642BSTS.pdf |
| Part Number | PLT0805Z6642BSTS |
|---|---|
| Pin Count | 2 |
| Operating Temperature | -55 to 125 °C |
| Product Dimensions | 2.03 x 1.27 x 0.84(Max) |
| Rad Hard | No |
| Case Style | Molded |
| Power Rating | 0.25 W |
| Case Size | 0805 |
| Type | Thin Film |
| Tolerance | 0.1 % |
| Mounting | Surface Mount |
| Supplier Package | 0805 |
| Package Type | SMD |
| Lead Finish | Tin|Silver|Copper |
| Temperature Coefficient | ±5 ppm/°C |
| Resistance Value | 66.4 kOhm |
| Termination Style | Wraparound |
| Product Depth | 1.27 mm |
| Product Height | 0.84(Max) mm |
| Product Length | 2.03 mm |
| Replacement Part Number | PART-PLT0805Z6642BSTS |
| Weight | Contact us |
| Country of Origin | - |
