Please contact us for more photos of PTN0603H30R1FST1
| Part Number | PTN0603H30R1FST1 |
|---|---|
| Manufacturer | Vishay |
| Quantity in stock | 689770 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Res Thin Film 0603 30.1 Ohm 1% 3 20W \u00b150ppm \u00b0C Molded SMD T R |
| Category | Resistor |
| Family | Resistor Fixed Single-Surface Mount |
| ROHS Compliant | Yes |
| MSL Level | PTN0603H30R1FST1 |
| Datasheet download |  PTN0603H30R1FST1.pdf |
| Part Number | PTN0603H30R1FST1 |
|---|---|
| Pin Count | 2 |
| Type | Thin Film |
| Lead Finish | Matte Tin Over Nickel |
| Case Size | 0603 |
| Case Style | Molded |
| Rad Hard | No |
| Product Dimensions | 1.62 x 0.81 x 0.5(Max) |
| Max Processing Temp | 260 |
| Operating Temperature | -55 to 155 °C |
| Temperature Coefficient | ±50 ppm/°C |
| Mounting | Surface Mount |
| Package Type | SMD |
| Resistance Value | 30.1 Ohm |
| Termination Style | Wraparound |
| Supplier Package | 0603 |
| Power Rating | 0.15 W |
| Tolerance | 1 % |
| Product Depth | 0.81 mm |
| Product Height | 0.5(Max) mm |
| Product Length | 1.62 mm |
| Replacement Part Number | PART-PTN0603H30R1FST1 |
| Weight | Contact us |
| Country of Origin | - |
