PTN0805H2003DST1 Vishay

PTN0805H2003DST1 Images

Please contact us for more photos of PTN0805H2003DST1

Part Number PTN0805H2003DST1
Manufacturer Vishay
Quantity in stock 700400 Pieces
Market Price -
Our Better Price Send by email: [email protected]
Delivery Time 1 day (can ship today)
Description Res Thin Film 0805 200K Ohm 0.5% 1 5W \u00b150ppm \u00b0C Molded SMD T R
Category Resistor
Family Resistor Fixed Single-Surface Mount
ROHS Compliant Yes
MSL Level PTN0805H2003DST1
Datasheet download PTN0805H2003DST1.pdf
Request Quotation for PTN0805H2003DST1

PTN0805H2003DST1 Specifications

Part Number PTN0805H2003DST1
Resistance Value 200 kOhm
Termination Style Wraparound
Tolerance 0.5 %
Package Type SMD
Pin Count 2
Case Size 0805
Product Dimensions 2.03 x 1.27 x 0.84(Max)
Type Thin Film
Lead Finish Matte Tin Over Nickel
Case Style Molded
Power Rating 0.2 W
Rad Hard No
Temperature Coefficient ±50 ppm/°C
Operating Temperature -55 to 155 °C
Supplier Package 0805
Max Processing Temp 260
Mounting Surface Mount
Product Depth 1.27 mm
Product Height 0.84(Max) mm
Product Length 2.03 mm
Replacement Part Number PART-PTN0805H2003DST1
Weight Contact us
Country of Origin -
