Please contact us for more photos of TNPW08051K07BHEA
| Part Number | TNPW08051K07BHEA |
|---|---|
| Manufacturer | Vishay |
| Quantity in stock | 519750 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Res Thin Film 0805 1.07KOhm 0.1% 1 8W \u00b150ppm \u00b0C Molded SMD Paper T R |
| Category | Resistor |
| Family | Resistor Fixed Single-Surface Mount |
| ROHS Compliant | Yes |
| MSL Level | TNPW08051K07BHEA |
| Datasheet download |  TNPW08051K07BHEA.pdf |
| Part Number | TNPW08051K07BHEA |
|---|---|
| Resistance Value | 1.07 kOhm |
| Termination Style | Wraparound |
| Pin Count | 2 |
| Lead Finish | Pure Tin Over Nickel |
| Type | Thin Film |
| Maximum Processing Temperature | 260 °C |
| Rad Hard | No |
| Package Dimensions | 2 x 1.25 x 0.45 mm |
| Case Size | 0805 |
| Case Style | Molded |
| Operating Temperature | -55 to 125 °C |
| Temperature Coefficient | ±50 ppm/°C |
| Power Rating | 1/8 W |
| Tolerance | 0.1 % |
| Mounting | Surface Mount |
| Supplier Package | 0805 |
| Product Depth | 1.25 mm |
| Product Height | 0.45 mm |
| Product Length | 2 mm |
| Product Weight | 5.5 mg |
| Replacement Part Number | PART-TNPW08051K07BHEA |
| Weight | Contact us |
| Country of Origin | - |
