| Part Number | TL494CNE4 |
|---|---|
| Manufacturer | Texas Instruments |
| Quantity in stock | 726650 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Voltage Mode PWM Controller 40V 200mA 16-Pin PDIP Tube |
| Category | Power Management IC |
| Family | PWM Controllers |
| ROHS Compliant | Yes |
| MSL Level | TL494CNE4 |
| Datasheet download |  TL494CNE4.pdf |
| Part Number | TL494CNE4 |
|---|---|
| Topology | Boost|Buck|Flyback|Forward|Full-Bridge|Half-Bridge|Push-Pull |
| Synchronous Pin | No |
| Operating Temperature | 0 to 70 °C |
| Rad Hard | No |
| Lead Finish | Gold |
| Max Processing Temp | 260 |
| Maximum Duty Cycle | 45 % |
| Number of PWM Outputs | 2 |
| Pin Count | 16 |
| Supplier Package | PDIP |
| Output Voltage | 40 V |
| Rise Time | 100 ns |
| On/Off Pin | No |
| Output Current | 200 mA |
| Adjustable Output | No |
| Switching Frequency | 300 kHz |
| Product Dimensions | 19.3 x 6.35 x 4.57 mm |
| Mounting | Through Hole |
| Fall Time | 40 ns |
| Package | 16PDIP |
| Replacement Part Number | PART-TL494CNE4 |
| Weight | Contact us |
| Country of Origin | - |
