Please contact us for more photos of BZV85-C12,113
| Part Number | BZV85-C12,113 |
|---|---|
| Manufacturer | Nexperia |
| Quantity in stock | 876980 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Diode Zener Single 12.05V 5% 1.3W 2-Pin DO-41 T R |
| Category | Discrete Semiconductor |
| Family | Diode |
| ROHS Compliant | Yes |
| MSL Level | BZV85-C12,113 |
| Datasheet download |  BZV85-C12,113.pdf |
| Part Number | BZV85-C12,113 |
|---|---|
| Rad Hard | No |
| MSL Level | 1 |
| Product Dimensions | 4.8 x 2.6 x 2.6 mm |
| Type | Voltage Regulator |
| Lead Finish | Tin |
| Operating Temperature | -65 to 200 °C |
| ESD Protection | No |
| Maximum Power Dissipation | 1300 mW |
| Zener Voltage Tolerance | 5 % |
| Maximum Zener Impedance | 10 Ohm |
| Test Current | 20 mA |
| Mounting | Through Hole |
| Supplier Package | DO-41 |
| Typical Voltage Temperature Coefficient | 8.55 mV/K |
| Pin Count | 2 |
| Maximum Reverse Leakage Current | 0.2 uA |
| Configuration | Single |
| Max Processing Temp | 260 |
| Nominal Zener Voltage | 12.05 V |
| Package | 2DO-41 |
| Replacement Part Number | PART-BZV85-C12,113 |
| Weight | Contact us |
| Country of Origin | - |
