Please contact us for more photos of BZX84-B8V2,235
| Part Number | BZX84-B8V2,235 |
|---|---|
| Manufacturer | Nexperia |
| Quantity in stock | 204650 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Diode Zener Single 8.2V 2% 250mW 3-Pin SOT-23 T R |
| Category | Discrete Semiconductor |
| Family | Diode |
| ROHS Compliant | Yes |
| MSL Level | BZX84-B8V2,235 |
| Datasheet download |  BZX84-B8V2,235.pdf |
| Part Number | BZX84-B8V2,235 |
|---|---|
| Test Current | 5 mA |
| Typical Voltage Temperature Coefficient | 4.6 mV/K |
| Maximum Zener Impedance | 15 Ohm |
| Operating Temperature | -65 to 150 °C |
| ESD Protection | No |
| Configuration | Single |
| Maximum Power Dissipation | 250 mW |
| Zener Voltage Tolerance | 2 % |
| Maximum Reverse Leakage Current | 0.7 uA |
| Max Processing Temp | 260 |
| Rad Hard | No |
| Pin Count | 3 |
| Mounting | Surface Mount |
| MSL Level | 1 |
| Nominal Zener Voltage | 8.2 V |
| Type | Voltage Regulator |
| Product Dimensions | 3 x 1.4 x 1 mm |
| Supplier Package | SOT-23 |
| Lead Finish | Tin |
| Package | 3SOT-23 |
| Replacement Part Number | PART-BZX84-B8V2,235 |
| Weight | Contact us |
| Country of Origin | - |
