Please contact us for more photos of PZU3.9B2,115
| Part Number | PZU3.9B2,115 |
|---|---|
| Manufacturer | Nexperia |
| Quantity in stock | 641620 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Diode Zener Single 3.985V 2% 550mW 2-Pin SOD-323F T R |
| Category | Discrete Semiconductor |
| Family | Diode |
| ROHS Compliant | Yes |
| MSL Level | PZU3.9B2,115 |
| Datasheet download |  PZU3.9B2,115.pdf |
| Part Number | PZU3.9B2,115 |
|---|---|
| Test Current | 5 mA |
| Configuration | Single |
| Supplier Package | SOD-323F |
| ESD Protection | No |
| Operating Temperature | -65 to 150 °C |
| Maximum Reverse Leakage Current | 3 uA |
| Nominal Zener Voltage | 3.985 V |
| Maximum Zener Impedance | 90 Ohm |
| Typical Voltage Temperature Coefficient | -2.5 mV/K |
| Zener Voltage Tolerance | 2 % |
| Product Dimensions | 1.8 x 1.35 x 0.8 mm |
| Maximum Power Dissipation | 550 mW |
| Pin Count | 2 |
| Max Processing Temp | 260 |
| Rad Hard | No |
| Lead Finish | Tin |
| MSL Level | 1 |
| Mounting | Surface Mount |
| Package | 2SOD-323F |
| Replacement Part Number | PART-PZU3.9B2,115 |
| Weight | Contact us |
| Country of Origin | - |
