Please contact us for more photos of 10106813-023112LF
| Part Number | 10106813-023112LF |
|---|---|
| Manufacturer | Amphenol-FCI |
| Quantity in stock | 833450 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn Board to Board M F 20 POS 0.5mm Solder ST SMD T R |
| Category | Connectors |
| Family | Connector Headers and PCB Receptacles |
| ROHS Compliant | Yes |
| MSL Level | 10106813-023112LF |
| Datasheet download |  10106813-023112LF.pdf |
| Part Number | 10106813-023112LF |
|---|---|
| Rad Hard | No |
| Number of Rows | 2 |
| Termination Method | Solder |
| Mounting | Surface Mount |
| Body Orientation | Straight |
| Maximum Voltage Rating | 500 V |
| Housing Color | Black |
| Operating Temperature | -40 to 125 °C |
| Lead Finish | Gold Over Nickel |
| Product Dimensions | 9.74 x 5.1 x 3 |
| Pin Count | 20 |
| Gender | M/F |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Copper Alloy |
| Maximum Current Rating | 0.5/Mated Contact Pair A |
| Type | Board to Board |
| Contact Plating | Gold Over Nickel |
| Number of Contacts | 20 |
| Pitch | 0.5 mm |
| Max Processing Temp | 260 |
| Maximum Contact Resistance | 50 mOhm |
| Product Depth | 5.1 mm |
| Product Height | 3 mm |
| Product Length | 9.74 mm |
| Replacement Part Number | PART-10106813-023112LF |
| Weight | Contact us |
| Country of Origin | - |
