Please contact us for more photos of 1-103957-5
| Part Number | 1-103957-5 |
|---|---|
| Manufacturer | TE Connectivity |
| Quantity in stock | 327730 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn IDC Connector RCP 5 POS 2.54mm IDT ST Cable Mount Strip |
| Category | Connectors |
| Family | Connector Headers and PCB Receptacles |
| ROHS Compliant | Yes |
| MSL Level | 1-103957-5 |
| Datasheet download |  1-103957-5.pdf |
| Part Number | 1-103957-5 |
|---|---|
| Contact Plating | Gold Over Nickel |
| Pitch | 2.54 mm |
| Lead Finish | Bright Tin |
| Contact Material | Phosphor Bronze |
| Rad Hard | No |
| Product Dimensions | 12.64 x 15.24 mm |
| Housing Material | Thermoplastic |
| Mounting | Cable Mount |
| Housing Color | Black |
| Body Orientation | Straight |
| Gender | RCP |
| Operating Temperature | -65 to 105 °C |
| Termination Method | IDT |
| Product Depth | 15.24 mm |
| Product Length | 12.64 mm |
| Replacement Part Number | PART-1-103957-5 |
| Weight | Contact us |
| Country of Origin | - |
