Please contact us for more photos of 84740-002
| Part Number | 84740-002 |
|---|---|
| Manufacturer | Amphenol-FCI |
| Quantity in stock | 436530 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn Board to Board PL 400 POS 1.27mm Solder ST SMD T R |
| Category | Connectors |
| Family | Connector Headers and PCB Receptacles |
| ROHS Compliant | Yes |
| MSL Level | 84740-002 |
| Datasheet download |  84740-002.pdf |
| Part Number | 84740-002 |
|---|---|
| Termination Method | Solder |
| Mounting | Surface Mount |
| Body Orientation | Straight |
| Lead Finish | Tin/Lead |
| Product Dimensions | 56.8 x 17.34 x 3.89 mm |
| Pitch | 1.27 mm |
| Contact Material | Copper Alloy |
| Operating Temperature | -40 to 85 °C |
| Max Processing Temp | 260 |
| Rad Hard | No |
| Contact Plating | Gold Over Nickel |
| Gender | PL |
| Housing Material | Liquid Crystal Polymer |
| Product Depth | 17.34 mm |
| Product Height | 3.89 mm |
| Product Length | 56.8 mm |
| Replacement Part Number | PART-84740-002 |
| Weight | Contact us |
| Country of Origin | - |
