Please contact us for more photos of 08055A100J4T2A
| Part Number | 08055A100J4T2A |
|---|---|
| Manufacturer | AVX |
| Quantity in stock | 117890 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Cap Ceramic 10pF 50V C0G 5% SMD 0805 125\u00b0C Paper T R |
| Category | Capacitors |
| Family | Capacitor Ceramic Multilayer |
| ROHS Compliant | Yes |
| MSL Level | 08055A100J4T2A |
| Datasheet download |  08055A100J4T2A.pdf |
| Part Number | 08055A100J4T2A |
|---|---|
| Pin Count | 2 |
| Military Standard | |
| Rad Hard | No |
| MSL Level | 1 |
| Capacitance Value | 10 pF |
| Product Dimensions | 2.01 x 1.25 x 0.94(Max) |
| Failure Rate | 4 |
| Tolerance | 5 % |
| Case Size | 0805 |
| Operating Temperature | -55 to 125 °C |
| Mounting | Surface Mount |
| Max Processing Temp | 260 |
| Dielectric | C0G |
| Supplier Package | 0805 |
| Voltage(DC) | 50 V |
| Construction | Flat |
| Package/Case | 0805 |
| Termination Style | Wraparound |
| Case Style | Ceramic Chip |
| Lead Finish | Tin Over Nickel |
| Product Depth | 1.25 mm |
| Product Height | 0.9(Max) mm |
| Product Length | 2.01 mm |
| Replacement Part Number | PART-08055A100J4T2A |
| Weight | Contact us |
| Country of Origin | - |
