Please contact us for more photos of CM05X7R822K16AH
| Part Number | CM05X7R822K16AH |
|---|---|
| Manufacturer | AVX |
| Quantity in stock | 173870 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Cap Ceramic 0.0082uF 16V X7R 10% SMD 0402 125\u00b0C T R |
| Category | Capacitors |
| Family | Capacitor Ceramic Multilayer |
| ROHS Compliant | Yes |
| MSL Level | CM05X7R822K16AH |
| Datasheet download |  CM05X7R822K16AH.pdf |
| Part Number | CM05X7R822K16AH |
|---|---|
| Max Processing Temp | 245 to 260|250 |
| Rad Hard | No |
| Tolerance | 10 % |
| Operating Temperature | -55 to 125 °C |
| Voltage(DC) | 16 V |
| Failure Rate | |
| Product Dimensions | 1 x 0.5 x 0.55 mm |
| Mounting | Surface Mount |
| Case Size | 0402 |
| Lead Finish | Tin |
| Military Standard | |
| Dielectric | X7R |
| Construction | Flat |
| Case Style | Ceramic Chip |
| Capacitance Value | 0.0082 uF |
| Package/Case | 0402 |
| Product Depth | 0.5 mm |
| Product Height | 0.55(Max) mm |
| Product Length | 1 mm |
| Replacement Part Number | PART-CM05X7R822K16AH |
| Weight | Contact us |
| Country of Origin | - |
