Please contact us for more photos of TPSD476K020R0200
| Part Number | TPSD476K020R0200 |
|---|---|
| Manufacturer | AVX |
| Quantity in stock | 633310 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Cap Tant Solid 47uF 20V D CASE 10% (7.3 X 4.3 X 2.9mm) SMD 7343-31 0.2 Ohm 125\u00b0C T R |
| Category | Capacitors |
| Family | Capacitor Tantalum Solid SMT |
| ROHS Compliant | Yes |
| MSL Level | TPSD476K020R0200 |
| Datasheet download |  TPSD476K020R0200.pdf |
| Part Number | TPSD476K020R0200 |
|---|---|
| Max Processing Temp | 260 |
| Rad Hard | No |
| Tolerance | 10 % |
| Case Style | Molded |
| Product Dimensions | 7.3 x 4.3 x 2.9 mm |
| Case Size | 7343-31 |
| Construction | Flat |
| Leakage Current | |
| Lead Finish | Matte Tin |
| Polarity | Polar |
| Mounting | Surface Mount |
| Case Code | D |
| Voltage(DC) | 20 V |
| Operating Temperature | -55 to 125 °C |
| MSL Level | 1 |
| Capacitance Value | 47 uF |
| Package/Case | 7343-31,D |
| Failure Rate | |
| Equivalent Series Resistance | |
| Dissipation Factor | |
| Military Standard | |
| Product Depth | 4.3 mm |
| Product Height | 2.9 mm |
| Product Length | 7.3 mm |
| Replacement Part Number | PART-TPSD476K020R0200 |
| Weight | Contact us |
| Country of Origin | - |
| Image | Part Number and Brand | Brief Description and PDF Datasheet |
|---|---|---|
|
AVX | Cap Tant Solid 100uF 10V C CASE 20% (6 X 3.2 X 2.6mm) SMD 6032-28 (1%FR) 1.2 Ohm 125\u00b0C T R Download PDF datasheet for TAJC107M010RNJV.pdf |
|
Vishay | Cap Tant Solid 100uF 10V D CASE 10% (7.3 X 4.3 X 2.8mm) SMD 7343-31 0.1 Ohm 125\u00b0C T R Download PDF datasheet for TR3D107K010C0100.pdf |
|
AVX | Cap Tant Solid 33uF 6.3V B CASE 20% (3.5 X 2.8 X 1.9mm) SMD 3528-21 0.07 Ohm 125\u00b0C T R Download PDF datasheet for TCJB336M006R0070.pdf |
|
AVX | Cap Tant Solid 22uF 16V C CASE 20% (6 X 3.2 X 2.6mm) SMD 6032-28 1 Ohm 125\u00b0C T R Download PDF datasheet for TAJC226M016RNJ.pdf |
|
AVX | Cap Tant Solid 2.2uF 50V B CASE 10% (3.5 X 2.8 X 1.9mm) SMD 3528-21 4.5 Ohm 125\u00b0C T R Download PDF datasheet for TAJB225K050RNJ.pdf |
|
Panasonic | Cap Tant Solid 15uF 25V D2 CASE 20% (7.3 X 4.3 X 1.9mm) SMD 7343,D2 0.09 Ohm 105\u00b0C Embossed T R Download PDF datasheet for 25TQC15MYFD.pdf |
|
KEMET | Cap Tant Solid 47uF 35V X CASE 20% (7.3 X 4.3 X 4mm) SMD 7343-43 0.07 Ohm 125\u00b0C T R Download PDF datasheet for T521X476M035ATE070.pdf |
|
AVX | Cap Tant Solid 2.2uF 50V D CASE 20% (7.3 X 4.3 X 2.9mm) SMD 7343-31 2.5 Ohm 125\u00b0C T R Download PDF datasheet for TAJD225M050RNJ.pdf |
|
KEMET | Cap Tant Solid 10uF 20V C CASE 10% (6 X 3.2 X 2.5mm) SMD 6032-28 1.8 Ohm 125\u00b0C T R Download PDF datasheet for T491C106K020AT.pdf |
|
KEMET | Cap Tant Solid 150uF 16V D CASE 10% (7.3 X 4.3 X 2.8mm) SMD 7343-31 0.7 Ohm 125\u00b0C T R Download PDF datasheet for T491D157K016AT.pdf |
