Please contact us for more photos of 142-0701-301
| Part Number | 142-0701-301 |
|---|---|
| Manufacturer | BEL |
| Quantity in stock | 315130 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn SMA RCP 0Hz to 18GHz 50Ohm Solder RA Thru-Hole Gold |
| Category | Connectors |
| Family | Connector RF |
| ROHS Compliant | Yes |
| MSL Level | 142-0701-301 |
| Datasheet download |  142-0701-301.pdf |
| Part Number | 142-0701-301 |
|---|---|
| Lead Finish | Gold |
| Rad Hard | No |
| Product Dimensions | 15.84 x 9.53 mm |
| Max Processing Temp | 260 |
| Contact Material | Beryllium Copper |
| Operating Temperature | -65 to 165 °C |
| Termination Method | Solder |
| Terminate To | PCB |
| Operating Frequency | 0 to 18 GHz |
| Mounting | Through Hole |
| Gender | RCP |
| Body Orientation | Right Angle |
| MSL Level | 1 |
| Contact Plating | Gold |
| Product Height | 9.53 mm |
| Product Length | 15.84 mm |
| Replacement Part Number | PART-142-0701-301 |
| Weight | Contact us |
| Country of Origin | - |
