SDR2207-150YL Bourns

SDR2207-150YL Images

Please contact us for more photos of SDR2207-150YL

Part Number SDR2207-150YL
Manufacturer Bourns
Quantity in stock 846070 Pieces
Market Price -
Our Better Price Send by email: [email protected]
Delivery Time 1 day (can ship today)
Description Ind Power Wirewound 15uH 15% 100KHz 38Q-Factor Ferrite 5A T R
Category Inductor
Family Inductor Surface Mount
ROHS Compliant Yes
MSL Level SDR2207-150YL
Datasheet download SDR2207-150YL.pdf
Request Quotation for SDR2207-150YL

SDR2207-150YL Specifications

Part Number SDR2207-150YL
Technology Wirewound
Operating Temperature -40 to 125 °C
Rad Hard No
Lead Finish Tin/Silver/Copper
Test Frequency 100 kHz
Max Processing Temp 250
Tolerance 15 %
Package/Case 22.3 X 15.3 X 7.8
Product Dimensions 22.3 x 15.3 x 7.8 mm
MSL Level 1
Product Depth 15.3 mm
Product Height 7.8 mm
Product Length 22.3 mm
Replacement Part Number PART-SDR2207-150YL
Weight Contact us
Country of Origin -
