CS5513-BSZR Cirrus Logic

CS5513-BSZR Images

Please contact us for more photos of CS5513-BSZR

Part Number CS5513-BSZR
Manufacturer Cirrus Logic
Quantity in stock 435170 Pieces
Market Price -
Our Better Price Send by email: [email protected]
Delivery Time 1 day (can ship today)
Description ADC Single Delta-Sigma 107sps 20-bit Serial 8-Pin SOIC T R
Category Data Conversion IC
Family ADC
ROHS Compliant Yes
MSL Level CS5513-BSZR
Datasheet download -
Request Quotation for CS5513-BSZR

CS5513-BSZR Specifications

Part Number CS5513-BSZR
Lead Finish Matte Tin
Mounting Surface Mount
Input Type Voltage
Minimum Single Supply Voltage 4.75 V
Resolution 20 Bit
Supplier Package SOIC
Number of Analog Inputs 1
Typical Dual Supply Voltage ±2.5|-1.7/3.3|-2/3 V
No Missing Codes 20 Bit
Pin Count 8
Typical Single Supply Voltage 5 V
Voltage Supply Source Single|Dual
Number of ADCs 1
Rad Hard No
Maximum Single Supply Voltage 5.25 V
Differential Input Yes
Single-Ended Input No
Input Signal Type Differential
Digital Interface Type Serial
Architecture Delta-Sigma
Integral Nonlinearity Error 0.0015 % of FSR
Product Dimensions 5 x 4 x 1.5 mm
Polarity of Input Voltage Bipolar
Operating Temperature -40 to 85 °C
Max Processing Temp 260
Voltage Reference External
Maximum Power Dissipation 400 mW
Sampling Rate 107 sps
Sample and Hold No
Digital Supply Support No
Package 8SOIC
Replacement Part Number PART-CS5513-BSZR
Weight Contact us
