Please contact us for more photos of PAM8303CBSC
| Part Number | PAM8303CBSC |
|---|---|
| Manufacturer | Diodes Incorporated |
| Quantity in stock | 589220 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Audio Amp Speaker 1-CH Mono Class-D 8-Pin MSOP T R |
| Category | Amplifiers IC |
| Family | Audio Amplifier |
| ROHS Compliant | Yes |
| MSL Level | PAM8303CBSC |
| Datasheet download |  PAM8303CBSC.pdf |
| Part Number | PAM8303CBSC |
|---|---|
| Typical Output Power x Channels @ Load | 3x1@4Ohm|1.8x1@8Ohm W |
| Screening Level | Industrial |
| Minimum CMRR | 40 dB |
| Power Supply Type | Single |
| Maximum Load Resistance | 8 Ohm |
| Typical PSRR | 63 dB |
| Pin Count | 8 |
| Typical Single Supply Voltage | 3.2|3.6|5 V |
| Output Type | 1-Channel Mono |
| Function | Speaker |
| Supplier Package | MSOP |
| Output Signal Type | Differential |
| Max Processing Temp | 250 |
| Product Dimensions | 3.1(Max) x 3.1(Max) x 0.94(Max) |
| Total Harmonic Distortion Noise | 0.55@[email protected]|0.5@[email protected] % |
| Rail to Rail | No |
| Maximum Single Supply Voltage | 5.5 V |
| Minimum Single Supply Voltage | 2.8 V |
| Amplifier Type | Class-D |
| Mounting | Surface Mount |
| Rad Hard | No |
| Input Signal Type | Differential |
| Operating Temperature | -40 to 85 °C |
| Package | 8MSOP |
| Replacement Part Number | PART-PAM8303CBSC |
| Weight | Contact us |
| Country of Origin | - |
