Please contact us for more photos of SMAJ20A-13-F
| Part Number | SMAJ20A-13-F |
|---|---|
| Manufacturer | Diodes Incorporated |
| Quantity in stock | 227730 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Diode TVS Single Uni-Dir 20V 400W 2-Pin SMA T R |
| Category | Circuit Protection |
| Family | TVS |
| ROHS Compliant | Yes |
| MSL Level | SMAJ20A-13-F |
| Datasheet download |  SMAJ20A-13-F.pdf |
| Part Number | SMAJ20A-13-F |
|---|---|
| Rad Hard | No |
| Max Processing Temp | 260 |
| Configuration | Single |
| Minimum Breakdown Voltage | 22.2 V |
| Maximum Peak Pulse Current | 12.3 A |
| Maximum Reverse Leakage Current | 5 uA |
| Pin Count | 2 |
| Operating Temperature | -55 to 150 °C |
| Test Current | 1 mA |
| Maximum Clamping Voltage | 32.4 V |
| Supplier Package | SMA |
| Lead Finish | Matte Tin |
| Direction Type | Uni-Directional |
| Peak Pulse Power Dissipation | 400 W |
| Product Dimensions | 4.6 x 2.92 x 2.1 mm |
| Maximum Reverse Stand-off Voltage | 20 V |
| MSL Level | 1 |
| ESD Protection | No |
| Mounting | Surface Mount |
| Package | 2SMA |
| Replacement Part Number | PART-SMAJ20A-13-F |
| Weight | Contact us |
| Country of Origin | - |
