Please contact us for more photos of HCP0805-R40-R
| Part Number | HCP0805-R40-R |
|---|---|
| Manufacturer | Eaton |
| Quantity in stock | 324010 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Ind High Current Power Shielded Wirewound 400nH 20% 100KHz Powdered Iron 20A T R |
| Category | Inductor |
| Family | Inductor Surface Mount |
| ROHS Compliant | Yes |
| MSL Level | HCP0805-R40-R |
| Datasheet download |  HCP0805-R40-R.pdf |
| Part Number | HCP0805-R40-R |
|---|---|
| Test Frequency | 100 kHz |
| Package/Case | 7.9 X 7.6 X 5 |
| Product Dimensions | 7.9 x 7.6 x 5 mm |
| Core Material | Powdered Iron |
| Rad Hard | No |
| Technology | Wirewound |
| Operating Temperature | -40 to 125 °C |
| Tolerance | 20 % |
| Protection Style | Shielded |
| Type | High Current Power |
| Product Depth | 7.6 mm |
| Product Height | 5 mm |
| Product Length | 7.9 mm |
| Replacement Part Number | PART-HCP0805-R40-R |
| Weight | Contact us |
| Country of Origin | - |
