Please contact us for more photos of 71V546S133PFG
| Part Number | 71V546S133PFG |
|---|---|
| Manufacturer | Integrated Device Technology |
| Quantity in stock | 589870 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | 3.3V 128K x 36 ZBT Synchronous PipeLined SRAM |
| Category | Memory IC |
| Family | SRAM Chip |
| ROHS Compliant | Yes |
| MSL Level | 71V546S133PFG |
| Datasheet download |  71V546S133PFG.pdf |
| Part Number | 71V546S133PFG |
|---|---|
| Lead Finish | Matte Tin |
| Mounting | Surface Mount |
| Timing Type | Synchronous |
| Minimum Operating Supply Voltage | 3.135 V |
| Maximum Operating Supply Voltage | 3.465 V |
| Number of I/O Lines | 36 Bit |
| Screening Level | Commercial |
| Maximum Operating Current | 300 mA |
| Number of Words | 128 kWords |
| Pin Count | 100 |
| Address Bus Width | 17 Bit |
| Density | 4.5 Mb |
| Number of Bits per Word | 36 Bit |
| Maximum Clock Rate | 133 MHz |
| Number of Ports | 1 |
| Architecture | Pipelined |
| Pitch | 0.65 |
| Supplier Package | TQFP |
| Maximum Random Access Time | 4.2 ns |
| Rad Hard | No |
| Max Processing Temp | 260 |
| Operating Temperature | 0 to 70 °C |
| Typical Operating Supply Voltage | 3.3 V |
| Data Rate Architecture | SDR |
| Moisture Sensitivity Level | 3 |
| MSL Level | 3 |
| Product Dimensions | 20 x 14 x 1.4 mm |
| Package | 100TQFP |
| Replacement Part Number | PART-71V546S133PFG |
| Weight | Contact us |
| Country of Origin | - |
