Please contact us for more photos of 501S42E9R1CV4E
| Part Number | 501S42E9R1CV4E |
|---|---|
| Manufacturer | Johanson Technology |
| Quantity in stock | 168840 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Cap Ceramic 9.1pF 500V C0G 0.25pF SMD 1111 125\u00b0C Embossed T R |
| Category | Capacitors |
| Family | Capacitor Ceramic Multilayer |
| ROHS Compliant | Yes |
| MSL Level | 501S42E9R1CV4E |
| Datasheet download |  501S42E9R1CV4E.pdf |
| Part Number | 501S42E9R1CV4E |
|---|---|
| Construction | Flat |
| Case Size | 1111 |
| Capacitance Value | 9.1 pF |
| Case Style | Ceramic Chip |
| Termination Style | Wraparound |
| Package Dimensions | 2.79 x 2.79 x 2.59 mm |
| Lead Finish | Tin Over Nickel |
| Tolerance | 0.25 pF |
| Pin Count | 2 |
| Voltage(DC) | 500 V |
| Rad Hard | No |
| Package/Case | 1111 |
| Maximum Processing Temperature | 260 °C |
| Operating Temperature | -55 to 125 °C |
| Supplier Package | 1111 |
| Mounting | Surface Mount |
| Dielectric | C0G |
| Product Depth | 2.79 mm |
| Product Height | 2.59(Max) mm |
| Product Length | 2.79 mm |
| Replacement Part Number | PART-501S42E9R1CV4E |
| Weight | Contact us |
| Country of Origin | - |
