| Part Number | MAX1109CUB+ |
|---|---|
| Manufacturer | Maxim Integrated |
| Quantity in stock | 542410 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | ADC Single SAR 50ksps 8-bit Serial 10-Pin uMAX |
| Category | Data Conversion IC |
| Family | ADC |
| ROHS Compliant | Yes |
| MSL Level | MAX1109CUB+ |
| Datasheet download |  MAX1109CUB+.pdf |
| Part Number | MAX1109CUB+ |
|---|---|
| Single-Ended Input | Yes |
| Resolution | 8 Bit |
| Sample and Hold | Yes |
| Digital Interface Type | Serial (4-Wire, SPI, QSPI, Microwire) |
| Max Processing Temp | 260|300 |
| Lead Finish | Matte Tin |
| Input Type | Voltage |
| Mounting | Surface Mount |
| Differential Nonlinearity | ±1 LSB |
| Maximum Power Dissipation | 444 mW |
| Input Voltage | 4.096|±2.048 V |
| Screening Level | Commercial |
| Architecture | SAR |
| Minimum Single Supply Voltage | 4.5 V |
| Number of Analog Inputs | 2|1 |
| Digital Supply Support | No |
| Pin Count | 10 |
| Typical Single Supply Voltage | 5 V |
| MSL Level | 1 |
| Voltage Reference | Internal|External |
| Integral Nonlinearity Error | ±0.5 LSB |
| Typical Power Dissipation | 0.475 mW |
| Voltage Supply Source | Single |
| Number of ADCs | 1 |
| Product Dimensions | 3.05 x 3.05 x 0.95 mm |
| Maximum Single Supply Voltage | 5.5 V |
| Supplier Package | uMAX |
| Polarity of Input Voltage | Unipolar|Bipolar |
| Operating Temperature | 0 to 70 °C |
| Differential Input | Yes |
| Input Signal Type | Single-Ended|Pseudo-Differential |
| Sampling Rate | 50 ksps |
| Full Scale Error | ±1 LSB |
| Rad Hard | No |
| Package | 10uMAX |
| Replacement Part Number | PART-MAX1109CUB+ |
| Weight | Contact us |
| Country of Origin | - |
