Please contact us for more photos of MAX764ESA+
| Part Number | MAX764ESA+ |
|---|---|
| Manufacturer | Maxim Integrated |
| Quantity in stock | 760670 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conv DC-DC Single Non-Inv Inv Step Up Step Down 3V to 16V 8-Pin SOIC N |
| Category | Power Management IC |
| Family | DC to DC Converter |
| ROHS Compliant | Yes |
| MSL Level | MAX764ESA+ |
| Datasheet download |  MAX764ESA+.pdf |
| Part Number | MAX764ESA+ |
|---|---|
| Switching Regulator | Yes |
| Switching Frequency | 300 kHz |
| Maximum Input Voltage | 16 V |
| Operating Supply Voltage | 3 to 16 V |
| Output Voltage | -1 to -16|-5 V |
| Product Dimensions | 5 x 4 x 1.5 mm |
| Pin Count | 8 |
| Screening Level | Extended |
| Minimum Input Voltage | 3 V |
| Operating Temperature | -40 to 85 °C |
| Maximum Output Current | 0.26 A |
| Output Type | Adjustable|Fixed |
| Type | Non-Inverting|Inverting|Step Up|Step Down |
| Number of Outputs | 1 |
| Efficiency | 80 % |
| Max Processing Temp | 260|300 |
| Mounting | Surface Mount |
| Load Regulation | 0.008 %/mA |
| Supplier Package | SOIC N |
| Line Regulation | 0.12 %/mV |
| MSL Level | 1 |
| Lead Finish | Matte Tin |
| Rad Hard | No |
| Package | 8SOIC N |
| Replacement Part Number | PART-MAX764ESA+ |
| Weight | Contact us |
| Country of Origin | - |
