Please contact us for more photos of 0022232091
| Part Number | 0022232091 |
|---|---|
| Manufacturer | Molex |
| Quantity in stock | 427530 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn Wire to Board HDR 9 POS 2.54mm Solder ST Thru-Hole Tube |
| Category | Connectors |
| Family | Connector Headers and PCB Receptacles |
| ROHS Compliant | Yes |
| MSL Level | 0022232091 |
| Datasheet download |  0022232091.pdf |
| Part Number | 0022232091 |
|---|---|
| Product Dimensions | 22.86 x 6.35 x 10.67 mm |
| Max Processing Temp | 235 |
| Pitch | 2.54 mm |
| Operating Temperature | 0 to 75 °C |
| Termination Method | Solder |
| Housing Color | White |
| Housing Material | Nylon |
| Gender | HDR |
| Contact Plating | Tin Over Copper |
| Mounting | Through Hole |
| Body Orientation | Straight |
| Contact Material | Brass |
| Product Depth | 6.35 mm |
| Product Height | 10.67 mm |
| Product Length | 22.86 mm |
| Replacement Part Number | PART-0022232091 |
| Weight | Contact us |
| Country of Origin | - |
