Please contact us for more photos of 0430451021
| Part Number | 0430451021 |
|---|---|
| Manufacturer | Molex |
| Quantity in stock | 399310 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn Wire to Board HDR 10 POS 3mm Solder RA Thru-Hole Tray |
| Category | Connectors |
| Family | Connector Headers and PCB Receptacles |
| ROHS Compliant | Yes |
| MSL Level | 0430451021 |
| Datasheet download |  0430451021.pdf |
| Part Number | 0430451021 |
|---|---|
| Contact Plating | Tin Over Nickel |
| Product Dimensions | 19.15 x 12.2 x 8.77 mm |
| Housing Material | Liquid Crystal Polymer |
| Mounting | Through Hole |
| Contact Material | Brass Alloy |
| Max Processing Temp | 260 |
| Body Orientation | Right Angle |
| Gender | HDR |
| Housing Color | Black |
| Pitch | 3 mm |
| Lead Finish | Tin |
| Operating Temperature | -40 to 105 °C |
| Termination Method | Solder |
| Product Depth | 12.2 mm |
| Product Height | 8.77 mm |
| Product Length | 19.15 mm |
| Replacement Part Number | PART-0430451021 |
| Weight | Contact us |
| Country of Origin | - |
