Please contact us for more photos of 0436500409
| Part Number | 0436500409 |
|---|---|
| Manufacturer | Molex |
| Quantity in stock | 776530 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn Wire to Board HDR 4 POS 3mm Solder RA SMD Embossed T R |
| Category | Connectors |
| Family | Connector Headers and PCB Receptacles |
| ROHS Compliant | Yes |
| MSL Level | 0436500409 |
| Datasheet download |  0436500409.pdf |
| Part Number | 0436500409 |
|---|---|
| Termination Method | Solder |
| Product Dimensions | 15.65 x 9.9 x 5.57 mm |
| Mounting | Surface Mount |
| Housing Color | Black |
| Operating Temperature | -40 to 105 °C |
| Contact Material | Brass |
| Body Orientation | Right Angle |
| Gender | HDR |
| Pitch | 3 mm |
| Lead Finish | Tin |
| Contact Plating | Tin Over Nickel |
| Max Processing Temp | 260 |
| Housing Material | Thermoplastic |
| Product Depth | 9.9 mm |
| Product Height | 5.57 mm |
| Product Length | 15.65 mm |
| Replacement Part Number | PART-0436500409 |
| Weight | Contact us |
| Country of Origin | - |
