Please contact us for more photos of 0781710004
| Part Number | 0781710004 |
|---|---|
| Manufacturer | Molex |
| Quantity in stock | 800970 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn Wire to Board HDR 4 POS 1.2mm Solder ST SMD Embossed T R |
| Category | Connectors |
| Family | Connector Headers and PCB Receptacles |
| ROHS Compliant | Yes |
| MSL Level | 0781710004 |
| Datasheet download |  0781710004.pdf |
| Part Number | 0781710004 |
|---|---|
| Operating Temperature | -25 to 85 °C |
| Pitch | 1.2 mm |
| Housing Material | Liquid Crystal Polymer |
| Contact Plating | Gold Over Nickel |
| Contact Material | Copper Alloy |
| Termination Method | Solder |
| Housing Color | Black |
| Gender | HDR |
| Body Orientation | Straight |
| Product Dimensions | 6.6 x 4.5 x 1.45 mm |
| Mounting | Surface Mount |
| Lead Finish | Gold |
| Product Depth | 4.5 mm |
| Product Height | 1.45 mm |
| Product Length | 6.6 mm |
| Replacement Part Number | PART-0781710004 |
| Weight | Contact us |
| Country of Origin | - |
