Please contact us for more photos of 0874380943
| Part Number | 0874380943 |
|---|---|
| Manufacturer | Molex |
| Quantity in stock | 305600 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn Shrouded Header HDR 9 POS 1.5mm Solder RA SMD Embossed T R |
| Category | Connectors |
| Family | Connector Headers and PCB Receptacles |
| ROHS Compliant | Yes |
| MSL Level | 0874380943 |
| Datasheet download |  0874380943.pdf |
| Part Number | 0874380943 |
|---|---|
| Housing Material | Thermoplastic |
| Product Dimensions | 14.8 x 5.75 x 4.45 mm |
| Contact Plating | Tin Over Nickel |
| Pitch | 1.5 mm |
| Operating Temperature | -55 to 105 °C |
| Housing Color | Natural |
| Termination Method | Solder |
| Mounting | Surface Mount |
| Lead Finish | Tin |
| Contact Material | Brass |
| Body Orientation | Right Angle |
| Gender | HDR |
| Product Depth | 5.75 mm |
| Product Height | 4.45 mm |
| Product Length | 14.8 mm |
| Replacement Part Number | PART-0874380943 |
| Weight | Contact us |
| Country of Origin | - |
