Please contact us for more photos of 34691-0202
| Part Number | 34691-0202 |
|---|---|
| Manufacturer | Molex |
| Quantity in stock | 554970 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn Wire to Board HDR 20 POS 2.54mm Solder RA Thru-Hole Tray |
| Category | Connectors |
| Family | Connector Headers and PCB Receptacles |
| ROHS Compliant | Yes |
| MSL Level | 34691-0202 |
| Datasheet download |  34691-0202.pdf |
| Part Number | 34691-0202 |
|---|---|
| Termination Method | Solder |
| Contact Material | Brass |
| Body Orientation | Right Angle |
| Gender | HDR |
| Mounting | Through Hole |
| Operating Temperature | -40 to 100 °C |
| Lead Finish | Tin |
| Contact Plating | Tin Over Nickel |
| Product Dimensions | 34.04 x 22.05 mm |
| Pitch | 2.54 mm |
| Rad Hard | No |
| Max Processing Temp | 260 |
| Housing Material | Thermoplastic |
| Housing Color | Brown |
| Product Height | 22.05 mm |
| Product Length | 34.04 mm |
| Replacement Part Number | PART-34691-0202 |
| Weight | Contact us |
| Country of Origin | - |
