Please contact us for more photos of 559592630
| Part Number | 559592630 |
|---|---|
| Manufacturer | Molex |
| Quantity in stock | 869590 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn Shrouded Header HDR 26 POS 2mm Solder RA Thru-Hole Tray |
| Category | Connectors |
| Family | Connector Headers and PCB Receptacles |
| ROHS Compliant | Yes |
| MSL Level | 559592630 |
| Datasheet download |  559592630.pdf |
| Part Number | 559592630 |
|---|---|
| Housing Color | Natural |
| Operating Temperature | -25 to 85 °C |
| Termination Method | Solder |
| Pitch | 2 mm |
| Product Dimensions | 29.4 x 14.5 x 11.7 mm |
| Body Orientation | Right Angle |
| Lead Finish | Tin |
| Contact Material | Brass |
| Gender | HDR |
| Housing Material | Polybutylene Terephthalate |
| Contact Plating | Tin |
| Mounting | Through Hole |
| Product Depth | 14.5 mm |
| Product Height | 11.7 mm |
| Product Length | 29.4 mm |
| Replacement Part Number | PART-559592630 |
| Weight | Contact us |
| Country of Origin | - |
