Please contact us for more photos of IRLR8259TRPBF
| Part Number | IRLR8259TRPBF |
|---|---|
| Manufacturer | Infineon |
| Quantity in stock | 140830 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Trans MOSFET N-CH 25V 57A 3-Pin(2+Tab) DPAK T R |
| Category | Discrete Semiconductor |
| Family | Transistor |
| ROHS Compliant | Yes |
| MSL Level | IRLR8259TRPBF |
| Datasheet download |  IRLR8259TRPBF.pdf |
| Part Number | IRLR8259TRPBF |
|---|---|
| Typical Turn-Off Delay Time | 9.1 ns |
| Typical Rise Time | 38 ns |
| Maximum Gate Source Voltage | ±20 V |
| RDS-on | 8.7@10V mOhm |
| Maximum Drain Source Voltage | 25 V |
| Lead Finish | Matte Tin |
| Product Dimensions | 6.73 x 6.22 x 2.39 mm |
| Typical Turn-On Delay Time | 8.4 ns |
| Maximum Continuous Drain Current | 57 A |
| Channel Type | N |
| Rad Hard | No |
| Mounting | Surface Mount |
| Typical Fall Time | 8.9 ns |
| Supplier Package | DPAK |
| MSL Level | 3 |
| Max Processing Temp | 260|300 |
| Pin Count | 3 |
| Channel Mode | Enhancement |
| Operating Temperature | -55 to 175 °C |
| Package | 3DPAK |
| Replacement Part Number | PART-IRLR8259TRPBF |
| Weight | Contact us |
| Country of Origin | - |
