Please contact us for more photos of NB638DL-LF-Z
| Part Number | NB638DL-LF-Z |
|---|---|
| Manufacturer | MPS |
| Quantity in stock | 732250 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conv DC-DC Single Step Down 4.5V 28V 20-Pin QFN EP T R |
| Category | Power Management IC |
| Family | DC to DC Converter |
| ROHS Compliant | Yes |
| MSL Level | NB638DL-LF-Z |
| Datasheet download |  NB638DL-LF-Z.pdf |
| Part Number | NB638DL-LF-Z |
|---|---|
| Output Voltage | 0.8 to 13 V |
| Pin Count | 20 |
| Type | Step Down |
| Maximum Output Current | 7 A |
| Switching Regulator | Yes |
| Rad Hard | No |
| Switching Frequency | 200 to 1000 kHz |
| Operating Supply Voltage | 4.5 to 28 V |
| Number of Outputs | 1 |
| Minimum Input Voltage | 4.5 V |
| Mounting | Surface Mount |
| Load Regulation | 5(Typ) % |
| Max Processing Temp | 260 |
| Screening Level | Extended Industrial |
| Operating Temperature | -40 to 125 °C |
| Product Dimensions | 3 x 4 x 0.95(Max) |
| Maximum Input Voltage | 28 V |
| Supplier Package | QFN EP |
| Output Type | Adjustable |
| Package | 20QFN EP |
| Replacement Part Number | PART-NB638DL-LF-Z |
| Weight | Contact us |
| Country of Origin | - |
