Please contact us for more photos of EKY-630EC3681MK40S
| Part Number | EKY-630EC3681MK40S |
|---|---|
| Manufacturer | Nippon ChemiCon |
| Quantity in stock | 561690 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Cap Aluminum 680uF 63V \u00b120% (12.5 X 40mm) Radial Aluminum Cylindrical Can 5mm 10000hr 105\u00b0C Bulk |
| Category | Capacitors |
| Family | Capacitor Aluminum |
| ROHS Compliant | Yes |
| MSL Level | EKY-630EC3681MK40S |
| Datasheet download |  EKY-630EC3681MK40S.pdf |
| Part Number | EKY-630EC3681MK40S |
|---|---|
| Mounting | Through Hole |
| Termination Style | Radial |
| Pin Count | 2 |
| Lead Pitch For Radial | 5 mm |
| Rad Hard | No |
| Lead Finish | Tin |
| Maximum Processing Temperature | 260 °C |
| Supplier Package | Radial |
| Package Dimensions | 12.5 x 40 mm |
| Package/Case | 12.5 X 40 |
| Tolerance | ±20 % |
| Construction | Aluminum Cylindrical Can |
| Leakage Current | 428.4@2Min uA |
| Operating Temperature | -40 to 105 °C |
| Capacitance Value | 680 uF |
| Lifetime | 10000 hr |
| Voltage(DC) | 63 Vdc |
| Product Diameter | 12.5 mm |
| Product Height | 40 mm |
| Replacement Part Number | PART-EKY-630EC3681MK40S |
| Weight | Contact us |
| Country of Origin | - |
