Please contact us for more photos of AXE130124D
| Part Number | AXE130124D |
|---|---|
| Manufacturer | Panasonic |
| Quantity in stock | 320300 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn Board to Board SKT 30 POS 0.4mm Solder ST SMD Embossed T R |
| Category | Connectors |
| Family | Connector Headers and PCB Receptacles |
| ROHS Compliant | Yes |
| MSL Level | AXE130124D |
| Datasheet download |  AXE130124D.pdf |
| Part Number | AXE130124D |
|---|---|
| Termination Method | Solder |
| Maximum Current Rating | 0.3/Contact A |
| Mounting | Surface Mount |
| Type | Board to Board |
| Pin Count | 30 |
| Number of Contacts | 80 |
| Pitch | 0.4 mm |
| Body Orientation | Straight |
| Product Dimensions | 8.5 x 1.9 x 0.77 |
| Housing Material | Liquid Crystal Polymer |
| Maximum Contact Resistance | 90 mOhm |
| Gender | SKT |
| Contact Material | Copper Alloy |
| Number of Rows | 2 |
| Rad Hard | No |
| Contact Plating | Gold Over Nickel |
| Lead Finish | Gold Over Nickel |
| Operating Temperature | -55 to 85 °C |
| Max Processing Temp | 260 |
| Product Depth | 1.9 mm |
| Product Height | 0.77 mm |
| Product Length | 8.5 mm |
| Replacement Part Number | PART-AXE130124D |
| Weight | Contact us |
| Country of Origin | - |
