Please contact us for more photos of ECA2GHG3R3B
| Part Number | ECA2GHG3R3B |
|---|---|
| Manufacturer | Panasonic |
| Quantity in stock | 575230 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Cap Aluminum 3.3uF 400V 20% (10 X 12.5mm) Radial Aluminum Cylindrical Can 5mm 40mA 2000 hr 105\u00b0C Ammo Pack |
| Category | Capacitors |
| Family | Capacitor Aluminum |
| ROHS Compliant | Yes |
| MSL Level | ECA2GHG3R3B |
| Datasheet download |  ECA2GHG3R3B.pdf |
| Part Number | ECA2GHG3R3B |
|---|---|
| Product Dimensions | 12.5 mm |
| Package/Case | 10 X 12.5 |
| Rad Hard | No |
| Termination Style | Radial |
| Tolerance | 20 % |
| Leakage Current | 89.2@2Min uA |
| Ripple Current | 40 mA |
| Construction | Aluminum Cylindrical Can |
| Max Processing Temp | 250 to 260 |
| Lead Pitch For Radial | 5 mm |
| Capacitance Value | 3.3 uF |
| Mounting | Through Hole |
| Lead Finish | Tin |
| Voltage(DC) | 400 V |
| Operating Temperature | -25 to 105 °C |
| Product Diameter | 10 mm |
| Product Height | 12.5 mm |
| Replacement Part Number | PART-ECA2GHG3R3B |
| Weight | Contact us |
| Country of Origin | - |
