Please contact us for more photos of ECWFD2W105K
| Part Number | ECWFD2W105K |
|---|---|
| Manufacturer | Panasonic |
| Quantity in stock | 586420 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Cap Film 1uF 450V PP 10% (17.5 X 7.8 X 11mm) Radial 15mm 105\u00b0C Bulk |
| Category | Capacitors |
| Family | Capacitor Film |
| ROHS Compliant | Yes |
| MSL Level | ECWFD2W105K |
| Datasheet download |  ECWFD2W105K.pdf |
| Part Number | ECWFD2W105K |
|---|---|
| Operating Temperature | -40 to 105 °C |
| Lead Pitch For Radial | 15 mm |
| Package/Case | 17.5(Max) X 7.8(Max) X 11(Max) |
| Voltage(DC) | 450 V |
| Termination Style | Radial |
| Pin Count | 2 |
| Mounting | Through Hole |
| Construction | Radial |
| Seated Plane Height | 12.5 mm |
| Capacitance Value | 1 uF |
| Product Dimensions | 17.5(Max) x 7.8(Max) x 11(Max) |
| Tolerance | 10 % |
| Supplier Package | Radial |
| Lead Finish | Tin |
| Rad Hard | No |
| Product Depth | 7.8(Max) mm |
| Product Height | 11(Max) mm |
| Product Length | 17.5(Max) mm |
| Replacement Part Number | PART-ECWFD2W105K |
| Weight | Contact us |
| Country of Origin | - |
