Please contact us for more photos of EEEFC1C101AP
| Part Number | EEEFC1C101AP |
|---|---|
| Manufacturer | Panasonic |
| Quantity in stock | 524400 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Cap Aluminum 100uF 16V 20% (8 X 6.2mm) SMD 230mA 1000 hr 105\u00b0C Embossed T R |
| Category | Capacitors |
| Family | Capacitor Aluminum |
| ROHS Compliant | Yes |
| MSL Level | EEEFC1C101AP |
| Datasheet download |  EEEFC1C101AP.pdf |
| Part Number | EEEFC1C101AP |
|---|---|
| Lead Finish | Tin/Bismuth |
| Capacitance Value | 100 uF |
| Product Dimensions | 6.2 mm |
| Rad Hard | No |
| Max Processing Temp | 260 |
| Tolerance | 20 % |
| Package/Case | 8 X 6.2 |
| Ripple Current | 230 mA |
| Mounting | Surface Mount |
| Leakage Current | 16@2Min uA |
| Construction | Cylindrical |
| Voltage(DC) | 16 V |
| Operating Temperature | -40 to 105 °C |
| Product Diameter | 8 mm |
| Product Height | 6.2 mm |
| Replacement Part Number | PART-EEEFC1C101AP |
| Weight | Contact us |
| Country of Origin | - |
